Three-phase voltage and current protection relay, 1–63 A, for DIN rail mounting, GKE-63T
- Regular price
- €79,60
- Regular price
-
- Sale price
- €79,60
- Unit price
- per
Couldn't load pickup availability
Notified by email when this product becomes available
Pre-order product
- Description
- Payment methods
- Warranty
Three-phase voltage and current protection relay for DIN rail mounting, Tense
The advanced Tense GKE-63T protection relay with an integrated microprocessor is designed to provide comprehensive protection for electrical equipment and motors against adverse conditions in the distribution network. The device continuously monitors network parameters and provides highly accurate protection against overvoltage, undervoltage, current overload, voltage asymmetry, phase failure or reversal, and internal overheating. The relay is equipped with an automatic reset function with an adjustable time delay and a memory for recording the last fault condition. The compact modular design is intended for easy installation on a standard 35 mm DIN rail.
Main Operating Modes
Synchronous Mode: Three-phase operation – if a fault occurs on one phase, the entire three-phase circuit is disconnected.
Asynchronous mode: Independent operation – each phase is monitored and disconnected separately (suitable for single-phase loads divided into three phases).
Technical Parameters
Product Type: Digital Protection Relay (Voltage and Current)
Number of phases: 3 (three-phase)
Rated current (adjustable): 1 – 63 A
Short-circuit trip time: 0.04 s
Neutral (N) break protection: Yes
Mounting method: 35 mm DIN rail
Setting ranges
Overvoltage protection: 220 – 300 V
Undervoltage protection: 80 – 210 V
Voltage asymmetry: 20 – 99 V
Start-up delay (Açılış gecikmesi): 1 – 300 s
Reset delay: 1 – 600 s
